Specifications
STRUCTURE
- Structural System: RCC framed structure designed for seismic compliant (Zone 3)
- Masonry:Solid Block 200 mm thk for external walls & 100mm for internal walls
- Internal floor level: From the Excisting Road level 3' 0" height will be raised
- Car Parking Level: From the Excisting Road level 1' 6" height will be raised
- Floor-Floor height (incl. slab): Shall be maintained at 3200mm
- Staircase Head room: Shall be maintained at 2745mm
- ATT: Anti-termite treatment will be done
WALL FINISH
- Internal walls:All internal walls will be finished with 2 coats of Asian putty, 1 coat of primer and 2 coats of Asian Tractor Emulsion paint
- Ceiling: Finished with 2coat Asian Roufe patty, 1 coat of primer and 2 coats of Asian Emulsion paint
- Exterior walls: Option-1- Finished with 1 coat of primer and 2 coats of Asian Exterior Emulsion paint, Option 2 -Texture Finish
- Bathroom: First quality Glazed ceramic tile up to 7'0"height of size 300 x 600 mm and above ceiling will be finished with a 2 coat patty ,1 Coat of primer and 2 Coats of Asian Tractor Emulsion paint
- Kitchen: First quality Ceramic wall tile of size 300 x 600 mm for a height of 600mm above the counter top finished level
- Toilet ceiling: Not applicable
FLOOR FINISH WITH SKIRTING
- Foyer, Living, Dining, Bedrooms & Kitchen First quality Vitrified tiles of size 1200 x 800 mm from Simpolo /Sunheart or equivalent will be provided.
- Bathroom,Balcony & Utility: First quality Anti-skid ceramic tiles of size 300 x 300 mm from Simpolo / Sunheart or equivalent will be provided.
- Open terrace (if applicable): Floors with pressed tiles
- External All round Area: Finished with Paver blocks or equivalent
KITCHEN & DINING
- KITCHEN : RCC Platform will be finished with granite slab of 600 mm width at height of 800 mm from the finished floor level
- Electrical point: For Water purifier, Exhaust & Chimney
- CP fitting: Chromium plated fittings of Jaquar or Equivalent will be provided
- Sink: Stainless steel sink with drain board will be provided
BALCONY
- Handrail: SS Handrail with Glass
- Staircase: MS handrail as per the architect's design
BATHROOMS
- Sanitary Fixture: Wall Mounted closet with health faucet from Parryware / CERA or equivalent in all bathrooms.
- CP fittings: Chromium plated fittings of Jaquar or equivalent Including Concealed diverter will be provided
- Electrical points: For Geyser & Exhaust fan points in all bathrooms will be provided.
- Wash Basin : Will be provided for all Bathrooms and Dining wherever applicable
JOINERY
- Main door: Prehung engineered wood/ ABS Door frame of size 1050 x 2100mm with 38mm thick ABS/ Engineeered wood Shutter of laminated finish with Pag or equivalent locks, towerbolts, doors viewer,door stopper.
- Bedroom doors: Prehung engineered wood/ ABS Door frame of size 900 x 2100mm with 35mm thick ABS /Engineered Shutter of laminated finish with Pag or equivalent locks, towerbolts,door stopper.
- Bathroom doors: Prehung engineered wood/ ABS Door frame of size 750 x 2100mm with 35mm thick ABS/Engineered wood Shutter of laminated finish with Pag or equivalent locks,towerbolts.
WINDOWS
- Windows: Powder Coated aluminum windows with sliding shutter Including Mosquito net with plain glass and MS grill on inner side wherever applicable
- French doors: Powder Coated aluminum frame with sliding shutter Including Mosquito net with Plain glass without grills.
- Ventilators: Powder Coated aluminum frame of fixed / louvered with Pinhead glass Without Grills.
ELECTRICAL POINTS
- Power supply: 3 PHASE power supply connection with separate meter will be provided for each villa in the main board located suitable place in the villa at the place of our choice
- Safety device: MCB & RCCB will be provided for Electrical circuit
- Switches & sockets: Modular boxes & modular switches of Panasonic or equivalent will be provided with including two control switch for one light and one fan in each Bedrooms
- Wires: Fire Retardant Low Smoke (FRLS) copper wire of a quality IS brand RR Kabel / Polycab or equivalent
- Data Point: Point in Living
- TV Point: Point in Living & Bedrooms
- Split A/C Point: Point will be provided in Living & Bedrooms.
- Exhaust fan Point: Point will be given in all bathrooms & Kitchen
- Geyser Point: Point will be provided in all bathrooms
COMMON FEATURES
- Lift: Not applicable
- Generator Backup :Inverter wiring provision for lighting / fan in all Rooms
- Name board :Not applicable
- Lift Fascia & Lift Lobby :Lift facia in stilt floor with Granite jambs.
- Lobby & Corridor :Stilt floor lobby with granite flooring & typical floors with tiles
- Staircase floor :Stilt floor with granite flooring & typical floors with tiles
- Staircase handrail :Interlocking paver blocks laid in Carpark area with car park number marked in paint.
- Terrace floor :Brick jelly concrete with Press Tiles
OUTDOOR FEATURES
- Bore well:5" Dia borewell for a sufficient depth with suitable motar will be provided.
- Water storage:Under Ground sump and Over head Tanks
- Rain water harvest :Rain water harvesting as per the MEP designs.
- Compound wall :Building perimeter fenced by compound wall with entry gates for a height of 1500mm
- Landscape :Suitable landscape at appropriate places
- CCTV :Wiring provision for External area only provide by Builder
- Electrical vehicle charger:Electrical vehicle charging bay will be provided at a suitable place.
